Led light bar Double Row Flood Beam 36W
Led light bar Double Row Flood Beam 36W
Truck Comfort LED Light Bar – Powerful Output and Wide Work-Area Illumination
This double-row LED light bar features 12 × 3 W LEDs, delivering a total power output of 36 W and 2640 lumens. Its flood beam provides broad illumination for working areas around your vehicle.
Designed for 9–32 V DC operation, it can be used with 12 V and 24 V vehicle systems. The aluminium housing, polycarbonate lens and IP67 protection provide a robust solution for outdoor and demanding working environments.
Key Benefits
- 36 W output: 12 × 3 W LEDs deliver 2640 lumens of illumination.
- Wide flood beam: provides broad coverage for work-area lighting.
- 12/24 V operation: supports a 9–32 V DC operating voltage range.
- IP67 protection: suitable for outdoor and demanding working environments.
- Durable construction: aluminium housing with a polycarbonate lens.
- Cool white light: 6000–6500 K colour temperature.
Applications
The LED light bar is designed for supplementary work-area lighting on trucks, lorries, tractors, off-road vehicles and other vehicles with 12 V or 24 V electrical systems.
Technical Specifications
- Manufacturer: Truck Comfort
- Power: 36 W
- LEDs: 12 × 3 W
- Luminous flux: 2640 lm
- Beam pattern: Flood
- Operating voltage: 9–32 V DC
- Nominal system: 12/24 V
- Colour temperature: 6000–6500 K
- Protection rating: IP67
- Operating temperature: −40 °C to +80 °C
- Dimensions: 275 × 90 × 120 mm
- Cable length: 60 cm
- Connection: Bare wire
- Housing material: Aluminium
- Lens material: Polycarbonate
- Bracket material: Aluminium
- Screw material: Steel
- Compliance markings / certifications: CE, RoHS, FCC, E9, IP67
Installation and Use
- Mount the LED light bar in the required position using the supplied aluminium bracket and steel screws.
- Connect the bare-wire cable to a suitable 9–32 V DC vehicle electrical system.
- Adjust the flood beam towards the required working area before fully tightening the mounting hardware.
- Check the mounting and electrical connection before use.
Package Contents
- LED light bar
- Aluminium mounting bracket
- Steel mounting screws
Important Information
This LED light bar is designed for 9–32 V DC operation and nominal 12/24 V vehicle systems. It uses a bare-wire connection. Check the vehicle electrical system and suitable mounting location before installation.
Choose this LED light bar for 36 W power, 2640 lm output and wide flood illumination when you need practical supplementary work lighting for your vehicle.
